Washer Not Agitating? Top-Load Washer Fixes

A washer not agitating usually comes down to one of three things: it is a high-efficiency model moving the clothes exactly as designed, the washer does not detect that the lid is closed and locked, or a part between the motor and the agitator has worn out. On a top-load washer, a few minutes of watching and one hand test usually tell you which, and most of the parts involved are inexpensive.

Unplug the washer before you reach into the tub or pull the cap off the agitator. Please never tape, jumper or bypass the lid switch or lid lock; it is what keeps hands out of a moving basket.

First, is it really not agitating?

Many newer top-loaders have no tall agitator post at all. They have an impeller, a low disc or cone in the bottom of the basket. Samsung explains the difference: an agitator rotates back and forth so the clothes rub against each other, while an impeller rotates to create a water current that makes the clothes rub against each other. The motion is gentler, the water is lower, and on some cycles the load barely seems to move. That is normal.

A few other normal pauses look like a washer that has stopped agitating:

• Sensing and filling. Many HE washers pause, or turn the basket slowly, while they sense the load and add water.
• Soak. GE notes that some of its models have soak cycles of 15 or 30 minutes before the main wash.
• Rebalancing. Whirlpool and Maytag say that when a top-loader detects an out-of-balance load, it refills and gently rotates back and forth to redistribute the clothes, which can look like weak agitation.
• A low-water cycle. Whirlpool says clothes can struggle to agitate on a low-water cycle, and that adding extra water can make them float instead of moving. For bulky items, choose a bulky or deep-fill cycle.

Washer not agitating? Checks you can do yourself

1. Watch a whole wash. Stay through the fill and the first several minutes. Note whether you hear the motor, whether anything moves and whether a light flashes.
2. Check the cycle. Make sure it is not set to soak or a delayed start, and was not paused.
3. Fix the load. Whirlpool says the load should be evenly distributed in the basket. One heavy item, like a comforter, can keep a top-loader stuck rebalancing.
4. Close the lid firmly and clean the lock. Whirlpool says detergent and lint buildup at the lid lock or on the striker (the piece on the lid that fits into the lock) can keep the lid from locking. Wipe both with a damp cloth. On some models you need to hold Start for up to 3 seconds.
5. Reset the power. Unplug the washer for a few minutes, plug it back in and start a new cycle. On GE top-loaders with the HydroWave wash system (select models made from 2011 through 2015), GE documents a motor reset: unplug the washer for 1 minute, plug it back in, then lift and lower the lid 6 times within 12 seconds, raising it at least 2 inches and closing it fully each time.
6. Do the hand test. With the washer unplugged and the basket empty, try turning the agitator by hand. On a two-piece agitator, the top section should turn freely in one direction and catch in the other. If the whole agitator spins freely with no resistance at all, the connection to the drive shaft has probably failed.

Top-load washer lid switch and lid lock

Every top-load washer has to confirm the lid is closed before it agitates. GE says its washers will not agitate or spin with the lid up, although many models still fill and drain and the timer still advances. That is why a bad lid switch fools people. GE also notes that if the plastic probe or the magnet on the lid is missing or damaged, the washer will not agitate or spin even with the lid closed.

Newer top-loaders lock the lid with a small motorized lock. Whirlpool says a flashing lid lock light means the lock did not move into position, the lock motor could not be powered, or something kept the lid from closing completely. If cleaning the striker does not fix it, the lid lock assembly is the usual repair.

Agitator not moving: agitator dogs and the drive block

On a two-piece agitator, the upper section is driven by a ring of small plastic cogs, usually called agitator dogs. They let the top turn one way and grab the other, which pulls clothes down into the water. When the dogs wear out, the bottom of the agitator moves but the top does not, and clothes float on top without turning over. They are an inexpensive part.

The agitator itself sits on a splined drive block over the transmission shaft. When the splines strip, the shaft turns but the agitator does not, and it spins freely by hand. Sometimes the agitator bolt has simply worked loose.

Whirlpool direct-drive washers and the motor coupling

Older Whirlpool direct-drive top-loaders connect the motor to the transmission through a motor coupling: two plastic drive forks with a rubber piece between them. The coupling is designed to break under overload, which protects the motor and transmission. When it breaks, you hear the motor run, but the washer neither agitates nor spins. It is a common failure after an overloaded wash, and an inexpensive repair.

Shift actuator, clutch and belt

• Shift actuator. Many newer high-efficiency top-loaders, including Maytag and Whirlpool models, use a shift actuator to switch between washing and spinning. When it fails, the washer may spin but never agitate, or agitate but never spin, and it often shows an error code.
• Clutch or mode shifter. Other designs change modes mechanically. A worn clutch or a failed shifter leaves the washer stuck in one mode.
• Belt. Belt-driven top-loaders use a belt between the motor and the transmission. A stretched belt slips, so the agitator barely moves and you may smell hot rubber; a broken belt means the motor runs and nothing else does.

What usually fails

• Lid switch or lid lock. The washer fills, then nothing moves; the lid light may flash.
• Agitator dogs. The bottom of the agitator moves; the top does not.
• Drive block. The motor runs; the agitator spins freely by hand.
• Motor coupling. The motor runs or hums; no agitation and no spin, often right after a heavy load.
• Shift actuator or clutch. Stuck in spin or stuck in wash, often with an error code.
• Belt. Weak or no agitation, sometimes with a burning rubber smell.
• Motor, timer or control. Silence when it should be agitating. The control is the least common cause and the priciest part, so we test everything else first.

If the washer also leaves water in the tub or skips the spin, start with washer not draining or spinning.

What it costs in Jacksonville

The diagnostic is $79 and is waived when you approve the repair. Washer repairs start at $179 labor plus parts, and you get a written flat-rate estimate before any work begins. Typical washer repairs run $200 to $400 all in on standard brands; lid switches and belts are toward the low end, while a transmission can run past $450. Many repairs can be finished on the first visit, and every repair carries our 90-day parts-and-labor warranty. See our pricing.

Repair or replace?

Washers typically last 8 to 12 years. A lid switch, coupling or set of agitator dogs is worth fixing on almost any washer. A transmission is different: if the washer is past the middle of its life and the repair costs more than half of a comparable new washer, replacing it usually makes more sense. Our repair-or-replace guide walks through the math.
